3000mm Lifting 3t 72V 480Ah Reach Forklift Trucks

1070mm Fork Length 3000mm Max Lifting Height For The 3ton 72V 480Ah Battery Electric Forklift

Features of FB30 3ton 72V 480Ah Battery Electric Forklift:

1.New adjustable seat makes operator more comfortable. Equipped with OPS or ORS seat and brake switch to prevent incorrect operation and secure the driver and the forklift from all sides.

2.Bigger and non-slip step: Bigger and non-slip step make the operating convenient and safe.

3.Equipped with original imported American Curtis electric control system; High voltage and large capacity battery can supply the forklift with strong power.

4.This electric forklift truck not only has excellent operability, comfortable, safe, and reliable performance with waterproof. In addition, it can also significantly more comfortable and more versatility.

The data of FB30 3ton 72V 480Ah Battery Electric Forklift
Specifications	1	Manufacturer			CNCHardware
	2	Model			FB30
	3	Load capacity		kg	3000
	4	Load center		mm	500
	5	Power unit			Battery
	6	Operator type			Driver/seat
	7	Tire type			Pneumatic
	8	Wheel(x=driving)	Front/rear		2X/2
Dimensions	9	Max. lifting height		mm	3000
	10	Free lift		mm	165
	11	Fork size	LWT	mm	107012545
	12	Tilt range	Mast forward/backward	deg	6/12
	13	Overall length(without fork)		mm	2510
	14	Total width		mm	1225
	15	Mast height (fork lowering)		mm	2075
	16	Overall height fork raised	With backrest	mm	4250
	17	Height to head guard		mm	2190
	18	Turning raduis(outside)		mm	2140
	19	Load distance		mm	480
	20	Min. right angle stacking aisle	not add load length & clearance	mm	2625
Performance	21	Speed	Max Travelling full load	km/h	13.5
			Max Travelling no load	km/h	15
			Lifting full load	mm/s	240
			Lifting no load	mm/s	450
	22	Gradeability	full load	%	12.5
Weight	23	Truck weight(with standard battery)		kg	4660
	24	Weight distribution	Full load front/rear	kg	6770/890
	25	Weight distribution	No load front/rear	kg	1885/2775
Chassis & Wheels	29	Tires	Number	front/rear	2/2
	30		Model	front axle	28*9-15-12PR
	31		Model	rear axle	18*7-8-14PR
	32	Wheelbase		mm	1600
	33	Tread	Front/rear	mm	1000/950
	34	Ground clearence	At lowest point(mast)	mm	140
	34	Ground clearence	Frame	mm	120
	35	Brake	Service brake		Hydraulic-foot pedal
	35	Brake	Parking break		Mechanical-hand lever
Drive Line	36	Battery	Voltage/capacity	V/AH/5hr	72V-480
	37	Battery	Weight with box (standard)	kg	1220
	38	Electric motor	AC Driving motor	kw	16.6
	39	Electric motor	DC Hydraulic driving motor	kw	10
	40		AC Hydraulic driving motor (as option)	kw	13.4
	41	Control type		Driving AC , lifting DC Driving AC , lifting AC(as option )
	42	Operating pressure		kg/cm²	175
