    Horizontal CNC Turning Machine Linear Motion Guideway Flat Bed Without Tailstock FL300

    Ask Lasest Price
    Payment Terms : T/T, L/C
    Brand Name : CNC Hardware
    Model Number : FL300
    Certification : CE
    Supply Ability : 3 set per month
    Delivery Time : 14 work days
    • Product Details
    • Company Profile

    Horizontal CNC Turning Machine Linear Motion Guideway Flat Bed Without Tailstock FL300

    Horizontal CNC Turning Machine Linear Motion Guideway Flat Bed Without Tailstock FL300

    Standard Features

    • Manual 3-Jaw Chuck (FL400+)
    • Pneumatic Collet (FL280, FL300)
    • Gang Type Tooling (For Swing < 400mm)
    • 4-Station Tool Post + Gang Plate (For Swing > 400mm)
    • Ergonomic Operator Panel Design
    • Automatic Lubrication System
    • Automatic Coolant System
    • Built-In Safety Features

    Horizontal CNC Turning Machine Linear Motion Guideway Flat Bed Without Tailstock FL300

    Optional Features

    • Updated Chucks
    • Updated Spring Collets
    • Updated Control Systems
    • Live Tooling
    • Bar Feeder
    • 8-Station Turret (Available on FL300/ FL400/ FL500/ FL550/ FL630)

    Specifications

    UnitFL300

    Capacity


    Chuck/collet

    Bed type/ guideway

    Max. swing dia. Over bed

    Max. length of workpiece

    Max. swing dia. Over slide


    type


    mm

    mm

    mm

    Pneumatic collet

    *Hydraulic collet, *chuck6”

    Flat/LM

    Φ300

    300, 180(chuck) *260(chuck)

    Φ135


    Spindle

    Spindle bore

    Max. dia. Of through hole

    Spindle nose


    Spindle speed


    Spindle motor power

    mmΦ48*Φ55*Φ62
    mmΦ40*Φ46*Φ52
    A2-5* A2-5*A2-6

    rpm

    3000*2500*2000
    *4500*4000*3500
    *5000*4000
    KW3.7/5.5, *5.5/7/5
    AxisX/Z travelmm350/300
    X/Z rapid traversemm/min25/15, *25/25

    Tool Post


    Type

    Gang type
    *4-station toolpost
    *8-station turret
    No. of tool stationsNo.4-10

    Others

    Power capacitykVA9
    Dimensions (LxWxH)mm1700x1200x1550
    Weight (about)Kg1800
    Note: *means optional
