Central Auto Lubrication 20KVA CNC Turning Machine

    Buy cheap Central Auto Lubrication 20KVA CNC Turning Machine from wholesalers

    Buy cheap Central Auto Lubrication 20KVA CNC Turning Machine from wholesalers
    • Buy cheap Central Auto Lubrication 20KVA CNC Turning Machine from wholesalers

    Central Auto Lubrication 20KVA CNC Turning Machine

    Ask Lasest Price
    Brand Name : CNCHardware
    Model Number : GT260
    Certification : CE
    Price :
    Payment Terms : T/T
    Supply Ability : 15 Sets per Month
    Delivery Time : 20 Days
    • Product Details
    • Company Profile

    Central Auto Lubrication 20KVA CNC Turning Machine

    Central Auto Lubrication Feature CNC Multi Turrets Turning Machine


    Standard Features

    • Hydraulic 3-Jaw Chuck
    • 8-Station Turret
    • Full Guard
    • Work Light
    • Tri-Color Alarm Light
    • Automatic Lubrication System
    • Automatic Coolant System

    Optional Features

    • 12-Station Turret
    • Different Chucks and Collets
    • Different CNC Control Systems
    • Different Spindle Speed and Bore Dia
    • Chip Conveyor
    • Tool Setter
    • Bar Feeder
    • Gang Type Tool Holders
    • Parts Catcher
    • Tailstock
    • Driven tool Turret

    Central Auto Lubrication 20KVA CNC Turning Machine

    Central Auto Lubrication 20KVA CNC Turning Machine

    Central Auto Lubrication 20KVA CNC Turning MachineCentral Auto Lubrication 20KVA CNC Turning Machine

    Specifications
    UnitGT260V

    Capacity

    Chuck Sizeinch8”
    Max Swing Dia. Over BedmmΦ580
    Max. Length of Workpiecemm340
    Max. Swing Dia. Over SlidemmΦ210

    Spindle

    Spindle BoremmΦ62
    Max Dia. of Through HolemmΦ52
    Spindle NosetypeA2-6
    Spindle Speedrpm4000, (2000 optional)
    Main Motor PowerkW11 / 15

    Axis

    X1 Axis Travelmm160
    Z1 Axis Travelmm350
    X2 Axis Travelmm160
    Z2 Axis Travelmm350
    X1/Z1 Rapid Traversem/min20
    X2/Z2 Rapid Traversem/min20

    Turret

    Turret1 Stations8
    Turret2 Stations8
    OD Tool Shank sizemm25
    Boring Bar SizemmΦ40

    Others

    Slant Bed Degree90°
    Guideway TypeLinear Motion Guideway
    Power CapacityKVA20KVA
    Overall Dimensionmm2850 x 1850 x 2300mm
    Weight (roughly)Kg7000Kg

    Central Auto Lubrication 20KVA CNC Turning Machine

    Standard Features

    • Hydraulic 3-Jaw Chuck
    • 8-Station Turret
    • Full Guard
    • Work Light
    • Tri-Color Alarm Light
    • Automatic Lubrication System
    • Automatic Coolant System

    Optional Features

    • 12-Station Turret
    • Different Chucks and Collets
    • Different CNC Control Systems
    • Different Spindle Speed and Bore Dia
    • Chip Conveyor
    • Tool Setter
    • Bar Feeder
    • Gang Type Tool Holders
    • Parts Catcher
    • Tailstock
    • Driven tool Turret

    Central Auto Lubrication 20KVA CNC Turning Machine

    Total Quality Management

    • No matter how far technology may evolve, the one ongoing concern of CNC customer is, “Will the machine make my parts, with higher productivity and without a hassle-And at a price I can justify?”
    • Customers deserve our best effort toward always providing quality, reliability, efficiency and low cost.
    • We have introduced the concept of TPS-Toyota quality system including -Total TQM Quality Management, which involves integrated control of quality, not just of the products but also service and communication, and all processes. We are working to provide quality that exceeds customer expectations.
    • Our machine Quality inspection process is far beyond the standard in the industry.
    • We combine scientific process, along with disciplined procedural systems to assure the highest quality total experience for our customers.
